APPENDIXG. ALARM LIST

B–63664EN/02

858

Number ContentsMessage

465 n AXIS : READ ID DATA FAILED At power–up, amplifier initial ID information could not be read.

466 n AXIS : MOTOR/AMP COMBINA-

TION

The maximum current rating for the amplifier does not match that for

the motor.

467 n AXIS : ILLEGAL SETTING OF

AXIS

The servo function for the following has not been enabled when an

axis occupying a single DSP (corresponding to two ordinary axes) is

specified on the axis setting screen.

1. Learning control (bit 5 of parameter No. 2008 = 1)

2. High–speed current loop (bit 0 of parameter No. 2004 = 1)

3. High–speed interface axis (bit 4 of parameter No. 2005 = 1)

468 HI HRV SETTING ERROR (AMP) Use of high–speed HRV is specified for a controlled axis of an ampli-

fier which does not support high–speed HRV.

The details of servo alarm No. 414 are displayed in the diagnosis display

(No. 200 and No.204) as shown below.

#7 #6 #5 #4 #3 #2 #1 #0

OVL

OVC HCA HVA DCA FBA OFA200

OFA : An overflow alarm is being generated inside of digital servo.

FBA : A disconnection alarm is being generated.

(This bit causes servo alarm No.416.The details are indicated

in diagnostic data No. 201)

DCA: A regenerative discharge circuit alarm is being generated in

servo amp.

Check LED.

HVA : An overvoltage alarm is being generated in servo amp.

Check LED.

HCA: An abnormal current alarm is being generated in servo amp.

Check LED.

OVC: A overcurrent alarm is being generated inside of digital servo.

LV : A low voltage alarm is being generated in servo amp.

Check LED.

OVL: An overload alarm is being generated.

(This bit causes servo alarm No. 400. The details are indicated

in diagnostic data No.201).

#7 #6 #5 #4 #3 #2 #1 #0

OFS

MCC LDA PMS204

PMS : A feedback pulse error has occured because the feedback cable

is defective.

LDA : The LED indicates that serial pulse coder C is defective

MCC : A magnetic contactor contact in the servo amplifier has

welded.

OFS : A current conversion error has occured in the digital servo.

The details of servo alarms No. 400 and No. 416 are displayed in the

diagnosis display (No. 201) as shown below.

#7 #6 #5 #4 #3 #2 #1 #0

ALD EXP201

When OVL equal 1 in diagnostic data No.200

(servo alarm No. 400 is being generated):

ALD

0 : Motor overheating

1 : Amplifier overheating

D Details of servo

alarm No.414

D Details of servo

alarms No. 400 and

No.416
