OPERATION
B–63664EN/02
11. SETTING AND DISPLAYING DATA
713
This subsection uses an example to describe how to display or set
machining menus (pattern menus) created by the machine tool builder.
Refer to the manual issued by the machine tool builder for the actual
pattern menus and pattern data. See II. PROGRAMMING for the pattern
data entry function.
Procedure for displaying the pattern data and the pattern menu
1 Press function key
OFFSET
SETTING
.
2 Press the continuous menu key , then press chapter selection
soft key
[MENU].
The following screen (pattern menu screen) is displayed:
1. TAPPING
2. DRILLING
3. BORING
4. POCKET
5. BOLT HOLE
6. LINE ANGLE
7. GRID
8. PECK
9.
10.
MENU : HOLE PATTERN O0000 N00000
> _
MDI **** *** *** 16:05:59
[ MACRO ] [ MENU ] [ OPR ] [ ] [ (OPRT) ]
3 Enter a pattern number and press soft key [SELECT].
In this example, press
5
, then press [SELECT].
The following screen (pattern data screen) is displayed:
NO. NAME DATA COMMENT
500 TOOL 0.000
501 STANDARD X 0.000 *BOLT HOLE
502 STANDARD Y 0.000 CIRCLE*
503 RADIUS 0.000 SET PATTERN
504 S. ANGL 0.000 DATA TO VAR.
505 HOLES NO 0.000 NO.500–505.
506 0.000
507 0.000
ACTUAL POSITION (RELATIVE)
X 0.000 Y 0.000
Z 0.000
VAR. : BOLT HOLE O0001 N00000
> _
MDI **** *** *** 16:05:59
[ OFFSET ] [SETING] [ ] [ ] [ (OPRT) ]
11.4.8
Displaying Pattern Data
and Pattern Menu
Procedure
Continuous menu key
MENU
