4. AUTOMATIC OPERATION
5 To execute a program, set the cursor on the head of the program. (Start
from an intermediate point is possible.) Push Cycle Start button on
the operator’s panel. By this action, the prepared program will start.
When the program end (M02, M30) or ER(%) is executed, the
prepared program will be automatically erased and the operation will
By command of M99, control returns to the head of the prepared
* * * *
* * * * * *
12 : 42 : 39
PROGRAM ( MDI )
G00 X100.0 Y200. ;
G01 Z120.0 F500 ;
M93 P9010 ;
G00 Z0.0 ;
G00 G90 G94 G40 G80 G50 G54 G69
G17 G22 G21 G49 G98 G67 G64 G15
6 To stop or terminate MDI operation in midway through, follow the
Stopping MDI operation
Press the feed hold switch on the machine operator’s panel. The
feed hold LED goes on and the cycle start LED goes off. The
machine responds as follows:
(i) When the machine was moving, feed operation decelerates
(ii) When dwell was being performed, dwell is stopped.
(iii) When M, T was being executed, the operation is stopped after
M, T is finished.
When the cycle start switch on the machine operator’s panel is
pressed, machine operation restarts.
b. Terminating MDI operation
key on the MDI panel.
Automatic operation is terminated and the reset state is entered.
When a reset is applied during movement, movement decelerates
