OPERATION

B–63664EN/02

12. GRAPHICS FUNCTION

743

It is possible to set whether the beam path is drawn by making the beam

length offset or cutter compensation valid or invalid.

Setting value Cutter compensation

0 Perform drawing by making cutter compensation valid

(An actual beam path is drawn.)

1 Perform drawing by making cutter compensation invalid

(A programmed path is drawn.)

Always set 0 before drawing when indicating the mark of the current

nozzle position.

Specify the color of the beam path. In the case of monochrome it is not

required to set it. The relationship between the setting value and color is

as shown below:

Setting value Color

0 White

1 Red

2 Green

3 Yellow

4 Blue

5 Purple

6 Light blue

⋅ PATH Specify the color of the beam path.

⋅ TOOL Specify the color of the current position mark of the beam.

⋅ AUTO CHANGE Set if for changing the color of the beam path

automatically according to the T –code command.

Setting value Function

0 The color of the beam path is not changed.

1 The color of the beam path is changed automatically.

When 1 is set, the setting value of the color designation of PATH is

incremented by 1 every time the T code is commanded. At the same time,

the color of the beam path changes. If the setting value exceeds 6, it returns

to 0.

Software key Function

[AUTO] Automatic scaling is performed. Obtain the maximum and

minimum coordinates of the part program before performing

drawing, specify them for the maximum and minimum values of

drawing parameters, and set the drawing magnification rate to

0 before starting drawing. Thus, the beam path view is properly

laid out on the screen.

[START] Drawing starts. When the [START] is pressed while the

drawing is not in STOP, the part program starts from the top of

the part program. Press the [START] while the drawing is in

stop to allow drawing to be carried out continuously.

[STOP] Stop drawing. (Single block stop)

[REWIND] Press this key to start drawing from the top of part program.

Searches for the beginning of a part program.

[ERASE] Erase the beam path view which has been drawn.

D Cutter compensation

D COLOR

D Soft key functions on the

“PATH GRAPHIC

[EXECUTION]”screen
