PROGRAMMING 18. SPECIFYING THE LASER FUNCTION

B–63664EN/02

345

Program Cutting condition screen Power control condition screen

POWER CTL POWER FREQUENCY DUTY PWR./SPEED VAR.0001 ;

-----------------

E001 ;

G91 G01 X70.0 ;

G01 Y100.0 ;

G01 X–70.0 ;

E003 ;

G01 X–30.0 ;

----------------

M30 ;

E001 901

E003 0

E901

E902

E910

15000

#6 #5

FLT

#4 #3 #2 #1 #0

LPC

0 : Disables the power control function.

1 : Enables the power control function.

If 0 is set, power control mode cannot be set. The G code or input signal

for entering power control mode is ignored.

FLT During power control, the first–order lag filter is:

0 : Disabled.

1 : Enabled.

When this parameter is set to 1, the first–order filter is applied to the

output command. This delays the output command.

The time constant of the filter is set in parameter No. 15094.

LP815089

LP7

LP6

LP5

LP4

LPZ

LPY

LPX

LP* Specifies whether to use the *–axis in feedrate calculation.

0 : Not use.

1 : Use.

The composite feedrate for the axes selected in this parameter is used to

calculate each laser output factor. If no axis is specified, it is assumed that

the first axis (LPX) and the second axis (LPY) are specified.

Parameter
