OPERATION

B–63664EN/02

11. SETTING AND DISPLAYING DATA

707

Various run times, the total number of machined parts, number of parts

required, and number of machined parts can be displayed. This data can

be set by parameters or on this screen (except for the total number of

machined parts and the time during which the power is on, which can be

set only by parameters).

This screen can also display the clock time. The time can be set on the

screen.

Procedure for Displaying and Setting Run Time, Parts Count and Time

1 Select the MDI mode.

2 Press function key

OFFSET

SETTING

3 Press chapter selection soft key

[SETING].

4 Press page key

PAGE

several times until the following screen

is displayed.

PARTS TOTAL = 14

PARTS REQUIRED = 0

PARTS COUNT = 23

POWER ON = 4H 31M

OPERATING TIME = 0H 0M 0S

CUTTING TIME = 0H 37M 5S

FREE PURPOSE = 0H 0M 0S

CYCLE TIME = 0H 0M 0S

DATE = 1993/07/05

TIME= 11:32:52

> _

MDI **** *** *** 16:05:59

[ OFFSET ] [ SETING ] [ WORK ] [ ] [ (OPRT) ]

SETTING (TIMER) O0001 N00000

5 To set the number of parts required, move the cursor to PARTS

REQUIRED and enter the number of parts to be machined.

6 To set the clock, move the cursor to DATE or TIME, enter a new date

or time, then press soft key

[INPUT].

11.4.4

Displaying and Setting

Run Time, Parts Count,

and Time

Procedure
